Consultants and systems integrators benefit from reduced labor and integration costs by removing the need to hard-wire devices into the patching systems. This eliminating extraneous cabling and conversion equipment – and the costs that come with it.
The Bittree Dante patchbay will interface with Dante Virtual Soundcard, countless Dante devices, and almost any analog component in the same system, including audio distribution equipment, digital audio workstations (DAWs), digital signal processors (DSPs), mixing consoles, multi-track recorders and video routers. The compact standalone or rack-mounted 1.5RU powder-coat enclosure carefully incorporates TT patching for audio I/O (16x16), redundant DC power in, external word clock I/O, network status, and audio VU multi-level LED metering.
Bryan Carpenter, senior sales consultant at Bittree, notes that the company’s Dante patchbay continues Bittree’s legacy of innovation over four decades. Bittree’s industry-firsts include the E3 connectorized audio patchbay and its patented, front-programmable audio technology.
“This is an ideal meeting of true innovators in engineering,” says Carpenter. “Audinate’s Dante innovation has been an undeniable game changer for integrators and end users in several industries, and has an exceptionally wide rate of acceptance within the manufacturing community. This patchbay streamlines the integration of analog and digital network audio patching, and establishes a foundation for interconnectivity across facilities within central equipment rooms, production studios, and IT closets among other locations. It is flexible enough to immediately solve problems in existing facilities, or optimize flexibility from the start in new facility designs.”
Bittree’s Dante patchbay supports a wide variety of audio sample rates ranging from 24-bit 44.1 to 192 kHz. The design integrates balanced TT connections to Dante analog and digital conversions, maintaining signal integrity and audio quality without requiring specialized patchbay circuit programming. Settings will be configurable using Dante Controller, including sample rates and channel assignments to and from Dante networks.
